Description
28
1 Glove compartment
2 Port console storage compartment (page 85)
3 Cleat
4 Horn (page 41)
5 Bilge pump outlet (page 104)
6 Anchor light socket (SX195 / SX190) (page
88)
7 Cooling water pilot outlet (page 115)
8 Swim platform (page 90)
9 Reboarding grip
10 Wet storage compartment (page 85)
11 Flush hose connector (page 132)
12 Ski tow hook
195S / SX195 / SX190
3
4
3
7
3
8
5
6
1
2
9
10
11
12
1
