Yamaha e60hmhd - Fuel Joint, Fuel Filter and Fuel Pump; Fuel Pump

E
FUEL JOINT, FUEL FILTER AND FUEL PUMP
Step Job/Part Q’ty Remarks
14
Fuel hose
1
(Fuel pump - carburetor)
15
Bolt (with washer)
2
16
Fuel pump
1
17
Gasket
1
Not reusable
For installation, reverse the removal
procedure.
4-3
