Yamaha e60hmhd - Anode and External Fittings Removal;Installation

E
ANODE AND EXTERNAL FITTINGS
ANODE AND EXTERNAL FITTINGS
REMOVING/INSTALLING THE ANODE AND EXTERNAL FITTINGS
Step Job/Part Q’ty Remarks
1
Bolt (with washer)
2
2
Anode cover
2
3
Grommet
2
4
Anode
2
5
Bolt
2
6
Spacer
1
7
Engine hunger
1
8
Bolt (with washer)
2
9
Bracket
1
10
Bolt (with washer)
2
11
Stay (left)
1
12
Bolt
1
13
Bracket
1
Continued on next page.
5-32
