PROPELLER SHAFT HOUSING ASSEMBLY
E
INSTALLING THE PROPELLER SHAFT
HOUSING ASSEMBLY
Install:
• Propeller shaft housing assembly
• Claw washer
• Ring nut
NOTE:
• To secure the ring nut, bend one tab into
the slot in the ring nut and the other tabs
toward the propeller shaft housing
assembly.
Ring nut wrench:
YB-34447/90890-06511..........
1
Ring nut wrench extension:
YB-06513/90890-06513..........
2
6-14
