SHIMMING
E
NOTE:
• There is no need to select shims when
reassembling with the original case and
inner parts.
• Shim calculations are required when
reassembling with the original inner parts
and a new case (the difference between the
original parts and new case).
• Measurements and adjustments are
required when replacing the inner part(s).
SHIMMING
6-30
