Yamaha e60hmhd - Removing;Installing the Power Unit

E
POWER UNIT
REMOVING/INSTALLING THE POWER UNIT
Step Job/Part Q’ty Remarks
Fuel line Refer to “REMOVING/INSTALLING THE
FUEL JOINT, FUEL FILTER AND FUEL
PUMP” on page 4-2.
Refer to “REMOVING/INSTALLING THE
CARBURETOR” on page 4-9.
1
Bolt (with washer)
4
2
Apron
2
3
Bolt (with washer)
6
4
Bolt (with washer)
2
5
Power unit
1
6
Dowel pin
2
7
Upper case gasket
1
Not reusable
For installation, reverse the removal
procedure.
5-19
