MAINTENANCE SPECIFICATIONS
ELECTRICAL
Unit
Model
Item Worldwide E60HMHD E60HWHD E60HWD
USA, Canada E60MH E60EH —
IGNITION SYSTEM
Ignition timing
Full retard Degrees A.T.D.C. 2 ± 1
Full advance Degrees B.T.D.C. 19 ± 1
Cam roller pick - up Degrees A.T.D.C. 2
Piston position
Full retard mm (in) A.T.D.C. 0.03 ± 0.02 (0.001 ± 0.001)
Full advanced mm (in) B.T.D.C. 2.42 ± 0.24 (0.095 ± 0.009)
CDI unit
Over revolution limiter
r/min
5,850 - 6,350
Over heat controlled revolution r/min 1,650 - 2,450
Spark plug gap mm (in) 0.9 (0.035)
Spark plug cap resistance
k
Ω
4.0 - 6.0
Ignition coil resistance
Primary (B/W - B)
Ω
0.18 - 0.26
Secondry (B/W - output)
k
Ω
3.8 - 5.8
Charge coil output peak voltage
@ cranking 1 (Br - B) V 129
@ cranking 2 (Br - B) V 103
@ 1,500 r/min (Br - B) V 151
@ 3,500 r/min (Br - B) V 120
Charge coil resistance
Ω
149 - 182
Pulser coil #1 output peak voltage
@ cranking 1 (W/R - B) V 2.4
@ cranking 2 (W/R - B) V 2.2
@ 1,500 r/min (W/R - B) V 6.1
@ 3,500 r/min (W/R - B) V 10.6
Pulser coil #1 resistance
Ω
117 - 143
Pulser coil #2 output peak voltage
@ cranking 1 (W/B - B) V 2.4
@ cranking 2 (W/B - B) V 2.2
@ 1,500 r/min (W/B - B) V 6.1
@ 3,500 r/min (W/B - B) V 10.6
Pulser coil #2 resitance
Ω
117 - 143
Pulser coil #3 output peak voltage
@ cranking 1 (W/G - B) V 2.4
@ cranking 2 (W/G - B) V 2.2
@ 1,500 r/min (W/G - B) V 6.1
@ 3,500 r/min (W/G - B) V 10.6
Pulser coil #3 resistance
Ω
117 - 143
CDI unit output peak voltage
@ cranking 1 (B/W - B) V —
@ cranking 2 (B/W - B) V 102
@ 1,500 r/min (B/W - B) V 141
@ 3,500 r/min (B/W - B) V 107
*Cranking 1: Open circuit voltage
Cranking 2: Loaded circuit voltage
2-6
