Yamaha e60hmhd - Crankcase Removal;Installation

E
CRANKCASE
CRANKCASE
REMOVING/INSTALLING THE CRANKCASE
Step Job/Part Q’ty Remarks
1
Bolt (with washer)
3
2
Oil seal housing assembly
1
3
Bolt
3
4
Cover
1
5
Gasket
1
Not reusable
6
Bolt (with washer)
6
7
Bolt (with washer)
8
8
Crankcase
1
9
Dowel pin
2
10
O-ring
1
2.4 x 68 mm
Not reusable
11
Oil seal
1
Not reusable
12
Oil seal
1
Not reusable
13
Oil seal housing
1
For installation, reverse the removal
procedure.
