E
Symbol
Unit
Model
World wide E60HMHD E60HWHD E60HWD
USA, Canada E60MH E60EH —
L6 (L)
mm (in) 1,020.6 (40.2) 1,020.6 (40.2) 1,020.6 (40.2)
(S)
mm (in) 913 (35.9) — —
L7
mm (in) 457 (18.0) 457 (18.0) 457 (18.0)
H1 (L)
mm (in) 954 (37.6) 954 (37.6) 954 (37.6)
(S)
mm (in) 831 (32.7) — —
H4 (L)
mm (in) 538 (21.2) 538 (21.2) 538 (21.2)
(S)
mm (in) 450 (17.7) — —
H6 (L)
mm (in) 753 (29.6) 753 (29.6) 753 (29.6)
(S)
mm (in) 670 (26.4) — —
H9
mm (in) 722 (28.4) 722 (28.4) 722 (28.4)
W5
mm (in) 322 (12.7) 322 (12.7) 322 (12.7)
A1
Degree 35 35 35
A2
Degree 67 67 67
A3
Degree 2.8 2.8 2.8
