Í If the 6Y8 Multifunction Meter is selected,
remove the caps and connect the coupler.
Î Do not route the wiring harness over the
bolt.
Ï If the 6Y8 Multifunction Meter is selected,
install the alert indicator coupler in the
location shown in the illustration.
Ñ If analog meters are selected, connect the
alert indicator coupler, and then install the
coupler in the location shown in the illus-
tration.
Ò Fasten the meter lead and extension wir-
ing harness using the holder.
È
Ë
Ì
5
7
8
3
7
É
Ò
9
0
8
C
4
3
1
2
Í
Ê
6
5
6
4
Ï
Î
Í
Ñ
Î
Ó
Õ
Ñ Ï
B
A
Ô
B
B
C-C
A-A
B
C
A A
C
Wiring harness routing
To Next Page
