Yamaha F200B - Fuel System; Blowby Gas Reburning System

2-14
2
Blowby gas reburning system
A blowby gas reburning system removes any unburned fuel from the blowby gases and sends it to
the combustion chambers to be burned.
È Blowby gas flow
É Engine oil
1 Intake silencer
2 Blowby gas separator (integrated with cylinder head cover)
È
É
1
2
Fuel system
