Yamaha F200B - Charging System; Starting System

1-10
1
Charging system
Starting system
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Lighting coil
Resistance (*1)
At 20 °C (68 °F) Ω 0.11–0.17
Output peak voltage
At cranking (unloaded) V 8.3
At 1500 r/min (unloaded) V 44.7
At 3500 r/min (unloaded) V 97.7
Fuse A 60
Rectifier Regulator
Output peak voltage
At 1500 r/min (loaded) V 13.0
At 3500 r/min (loaded) V 13.0
(*1) The figures are for reference only.
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Starter motor
Type Sliding gear
Output kW 1.4
Cranking time limit second 30
Brush
Standard length mm (in) 15.5 (0.61)
Wear limit mm (in) 9.5 (0.37)
Commutator
Standard diameter mm (in) 29.0 (1.14)
Wear limit mm (in) 28.0 (1.10)
Standard undercut mm (in) 0.5–0.8 (0.02–0.03)
Wear limit mm (in) 0.2 (0.01)
Electrical system technical data
