1-11
SPEC
Specification
Gauge/sensor
Fuel system technical data
Fuel system
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Water pressure sensor
Input voltage V 4.75–5.25
Output voltage (*1)
At 392.0 kPa (3.92
kgf/cm
2
, 56.8 psi)
V2.5
At 784.0 kPa (7.84
kgf/cm
2
, 113.7 psi)
V4.5
Speed sensor
Input voltage V 4.75–5.25
Output voltage (*1)
At 392.0 kPa (3.92
kgf/cm
2
, 56.8 psi)
V2.5
At 784.0 kPa (7.84
kgf/cm
2
, 113.7 psi)
V4.5
(*1) The figures are for reference only.
Item Unit
Model
F200BET FL200BET F250GET FL250GET
Fuel filter assembly
Holding pressure
Positive pressure
kPa
(kgf/cm
2
,
psi)
200.0 (2.00, 29.0)
Negative pressure
kPa
(kgf/cm
2
,
psi)
80.0 (0.80, 11.6)
Primer pump
Holding pressure
Positive pressure
kPa
(kgf/cm
2
,
psi)
170.0 (1.70, 24.7)
Vapor separator tank
Float height mm (in) 67.5 ± 2.5 (2.66 ± 0.10)
Canister
Holding pressure
Positive pressure
kPa
(kgf/cm
2
,
psi)
19.6 (0.196, 2.8)
