Yamaha F200B - Page 256

6-47
FUEL
Fuel system
6. Fasten the wiring harness using the hold-
ers 4, and then fasten the wiring har-
ness using the plastic ties 6. See
“Wiring harness routing” (5-6).
7. Install the fuel rail covers 7 and 8.
8. Connect the quick connectors. See “Con-
necting the quick connector” (6-8).
9. Fasten the fuel hoses 9 and 0 using the
holders A, B, and C.
6
6
PORT STBD
d
4
d
4
7
PORT
8
STBD
0
B
9
A
PORT
0
C
STBD
