Yamaha F200B - Page 41

1-18
1
PTT relay terminal nut — 40.43.0
Engine ECM bolt M6 7 0.7 5.2
Timing belt tensioner bolt — 39 3.9 28.8
Pulley bolt M10 39 3.9 28.8
Cylinder head cover bolt
1st
M6
80.85.9
2nd 8 0.8 5.9
Ignition coil bolt M6 7 0.7 5.2
Spark plug — 25 2.5 18.4
Cylinder head cover plate screw M4 2 0.2 1.5
Adapter plug M14 23 2.3 17.0
Camshaft cap bolt
1st
M7
80.85.9
2nd 17 1.7 12.5
VCT cap — 32 3.2 23.6
VCT bolt M12 60 6.0 44.3
Driven sprocket bolt M10 60 6.0 44.3
Exhaust cover bolt
1st
M6
60.64.4
2nd 12 1.2 8.9
Exhaust outer cover plug M18 55 5.5 40.6
OCV bolt M6 7 0.7 5.2
Engine hanger bolt M6 12 1.2 8.9
Cylinder head bolt
1st
M8
14 1.4 10.3
2nd 28 2.8 20.7
Cylinder head bolt
(When using a new bolt)
1st
M10
30 3.0 22.1
2nd 60 6.0 44.3
3rd Loosen completely
4th 30 3.0 22.1
5th 60 6.0 44.3
6th 90°
Cylinder head bolt
(When reusing the bolt)
1st
M10
27 2.7 19.9
2nd 54 5.4 39.8
3rd Loosen completely
4th 27 2.7 19.9
5th 54 5.4 39.8
6th 90°
Oil pressure sensor — 18 1.8 13.3
Oil filter — 18 1.8 13.3
Oil filter union bolt UNF 34 3.4 25.1
Crankcase cover bolt
1st
M8
14 1.4 10.3
2nd 28 2.8 20.7
Cooling water passage cover bolt M6 12 1.2 8.9
Knock sensor — 32 3.2 23.6
Engine temperature sensor — 15 1.5 11.1
Oil pump cover screw — 40.43.0
Crankcase bolt
1st
M10
33 3.3 24.3
2nd 90°
Crankcase bolt (length: 93 mm)
1st
M8
28 2.8 20.7
2nd 90°
Part to be tightened Screw size
Tightening torques
N·mkgf·mft·lb
Specified tightening torque
