PM5D/PM5D-RH Owner’s Manual Reference section 347
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
❏ Analog Input (1-48)
❏ Analog Input (ST IN1-4 [L,R])
❏ Analog Input (2TR IN ANALOG1,2 [L,R])
❏ Digital Input (2TR IN DIGITAL1-3)
❏ Talkback Input
❏ Oscillator
❏ STEREO A,B [L,R], MIX1-24, MATRIX1-8
❏ MONITOR OUT [L,C,R], CUE OUT
❏ PHONES (x2)
❏ Digital Output (2TR OUT DIGITAL1-3)
Connector XLR-3-31 Type (Balanced) x48
Phantom Power
PM5D: +48V DC is supplied to Input by individual mechanical switch
PM5D-RH: +48V DC is supplied to Input by individual software control
Pad Switch PM5D: 0/26 dB attenuation
Gain Control
PM5D: 44 dB detented
–60 dB to –16 dB (PAD=OFF), –34 to +10 dB (PAD=ON)
PM5D-RH: 72 dB by software control
–62 dB to 10 dB (1 dB step)
Peak Indicator Red LED is lit when post HA level reaches 3 dB below clipping
Signal Indicator Green LED is lit when post HA level reaches 14 dB below nominal
Insert (Pre AD converter) PM5D: Out, In (TRS Balanced)
Insert Switch PM5D: On/Off
AD Converter 24bit linear, 128 times oversampling
Connector XLR-3-31 Type (Balanced) x8
Phantom Power PM5D-RH: +48V DC is supplied to Input by individual software control
Gain Control
PM5D: 44 dB detented
–34 dB to +10 dB
PM5D-RH: 72 dB by software control
–62 dB to +10 dB (1 dB step)
Peak Indicator Red LED is lit when post HA level reaches 3 dB below clipping
Signal Indicator Green LED is lit when post HA level reaches 14 dB below nominal
AD Converter 24bit linear, 128 times oversampling
Connector XLR-3-31 Type (Balanced) x4
Gain Switch +24 dBu (default) / +18 dBu
AD Converter 24bit linear, 128 times oversampling
Connector
AES/EBU XLR-3-31 Type (Balanced) x2 (DIGITAL
IN 1,2)
SPDIF RCA PIN (DIGITAL IN 3)
Sampling Rate
Converter
On/Off by software control (1:3 and 3:1 maxi-
mum input to output sample rate ratio)
Connector XLR-3-31 Type (Balanced)
Phantom Power +48V DC is supplied by software control
Gain 50 dB fixed (pre level control)
AD Converter 24bit linear, 128 times oversampling
Talkback Select
TALKBACK IN and selected INPUT1-48 can be
used simultaneously
Level 0 to –96dB (1dB step)
On/Off Dedicated switch and software control
Waveform
MODE: Sine Wave 1ch, Sine Wave 2ch, Pink
Noise, Burst Noise
Sine Waveform: 100Hz, 1kHz, 10kHz
Routing MIX1-24, MATRIX1-8, STEREO A,B (L,R)
Connector XLR-3-32 Type (Balanced)
DA Converter 24bit linear, 128 times oversampling
Connector XLR-3-32 Type (Balanced)
DA Converter 24bit linear, 128 times oversampling
Level Control Analog potentiometer
Connector TRS
Level Control Analog potentiometer
Connector
AES/EBU XLR-3-32 Type (Balanced) x2 (DIGITAL
OUT 1,2)
SPDIF RCA PIN (DIGITAL OUT 3)
Sampling Rate
Converter
On/Off by software control (1:3 and 3:1 maxi-
mum input to output sample rate ratio)
