PM5D/PM5D-RH Owner’s Manual Reference section 349
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
❏ Analog Output Characteristics
*1. XLR-3-32 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
*2. Phone jacks are balanced. (Tip=HOT, Ring=COLD, Sleeve=GND)
*3. PHONES stereo phone jacks are unbalanced. (Tip=LEFT, Ring=RIGHT, Sleeve=GND)
*4. There are switches inside the body to preset the maximum output level.
*5. INSERT OUTs are only provided for PM5D.
*6. The position of the level control is 10 dB lowered from Max.
* In these specifications, 0 dBu = 0.775 Vrms.
* All output DA converters are 24bit, 128 times (@48 kHz) oversampling.
❏ Digital Input Characteristics
❏ Digital Output Characteristics
*1. The channel status of 2TR OUT DIGITAL 1,2 is described on page 350.
*2. The channel status of 2TR OUT DIGITAL 3 is described on page 350.
*3. Dither: word length 16/20/24 bit
*4. XLR-3-32 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
Output
Terminals
Actual Source
Impedance
For Use With
Nominal
GAIN SW
*4
Output Level
Connector
Nominal Max. Before Clip
STEREO A,B [L,R] 150Ω 600Ω Lines
+24 dB (default) +4 dBu (1.23 V) +24 dBu (12.28 V)
XLR-3-32 Type
(Balanced)
*1
+18 dB –2 dBu (616 mV) +18 dBu (6.16 V)
MONITOR OUT
[L,R,C]
150Ω 600Ω Lines
+24 dB (default) +4 dBu (1.23 V) +24 dBu (12.28 V)
XLR-3-32 Type
(Balanced)
*1
+18 dB –2 dBu (616 mV) +18 dBu (6.16 V)
CUE OUT [L,R] 150Ω 600Ω Lines
+24 dB (default) +4 dBu (1.23 V) +24 dBu (12.28 V)
XLR-3-32 Type
(Balanced)
*1
+18 dB –2 dBu (616 mV) +18 dBu (6.16 V)
MATRIX OUT 1-8 150Ω 600Ω Lines
+24 dB (default) +4 dBu (1.23 V) +24 dBu (12.28 V)
XLR-3-32 Type
(Balanced)
*1
+18 dB –2 dBu (616 mV) +18 dBu (6.16 V)
MIX OUT 1-24 150Ω 600Ω Lines
+24 dB (default) +4 dBu (1.23 V) +24 dBu (12.28 V)
XLR-3-32 Type
(Balanced)
*1
+18 dB –2 dBu (616 mV) +18 dBu (6.16 V)
INSERT OUT 1-48 150Ω 10kΩ Lines — +4 dBu (1.23 V) +24 dBu (12.28 V)
Phone Jack (TRS)
(Balanced)
*2 *5
PHONES (x 2) 15Ω
8Ω Phones
—
75 mW
*6
150 mW
Stereo Phone Jack
(TRS) (Unbalanced)
*3
40Ω Phones
65 mW
*6
150 mW
Terminal Format Data Length Level Connector
2TR IN DIGITAL
1 AES/EBU AES/EBU 24bit RS422
XLR-3-31 Type (Balanced)
*1
*1. XLR-3-31 type connectors are balanced. (1=GND, 2=HOT, 3=COLD)
2 AES/EBU AES/EBU 24bit RS422
XLR-3-31 Type (Balanced)
*1
3 COAXIAL IEC-60958 24bit 0.5Vpp/75Ω RCA Pin Jack
CASCADE IN — RS422 D-Sub Half Pitch Connector 68P (Female)
Terminal Format Data Length Level Connector
2TR OUT DIGITAL
1 AES/EBU
AES/EBU
*1
Professional Use
24bit
*3
RS422
XLR-3-32 Type (Balanced)
*4
2 AES/EBU
AES/EBU
*1
Professional Use
24bit
*3
RS422
XLR-3-32 Type (Balanced)
*4
3 COAXIAL
IEC-60958
*2
Consumer Use
24bit
*3
0.5Vpp/75Ω RCA Pin Jack
CASCADE OUT — RS422 D-Sub Half Pitch Connector 68P (Female)
