PM5D/PM5D-RH Owner’s Manual Reference section 351
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
❏ Control I/O Characteristics
*1. XLR-3-31 type connectors are balanced. (1/Sleeve=GND, 2/Tip=HOT, 3/Ring=COLD)
*2. 4pin=HOT, 3pin=COLD, Lamp rating 5 W, Voltage control by variable volume
*3. Inputs: 4 channels, Outputs: 12 channels
Input Pin: AD Converter (7bit, 128steps, Voltage Detection Range: 0-5V, Maximum Rating: 5V)
Output Pin: Open Collector (Vmax=12V, Imax/pin=75 mA, GPO1-8: Total Imax=300 mA, GPO9-12: Total Imax=300 mA)
Power Pin: Power Supply (Vp=5V, Imax/2 pin=500 mA)
❏ SLOT 1-4 Characteristics
Terminal Format Level Connector
TO HOST USB USB 1.1
—
B Type USB Connector
MIDI
IN
MIDI DIN Connector 5PTHRU
OUT
TIME CODE IN SMPTE SMPTE 0.3Vpp(Min)/10.0Vpp(Max), 10kΩ
XLR-3-31 Type (Balanced)
*1
WORD CLOCK
IN
—
TTL/75Ω (ON/OFF)
BNC Connector
OUT TTL/75Ω
GPI
—
—
D-Sub Connector 25P (Female)
*3
HA REMOTE
RS422
D-Sub Connector 9P (Male)
RS422 REMOTE D-Sub Connector 9P (Female)
KEYBOARD
PS/2 — DIN Connector 6P
MOUSE
LAMP 1,2,3
—
2.5V - 11.5V
XLR-4-31 Type
*2
MEMORY CARD — PCMCIA (Compact Flash)
Card Name Function Input Output
The Number Of
Usable Cards
MY8-AT ADAT
8 IN 8 OUT
4
MY8-TD TASCAM
MY8-AE AES/EBU
MY4-AD
ANALOG IN
4 IN
—
MY8-AD 8 IN
MY4-DA ANALOG OUT — 4 OUT
MY8-AD24
ANALOG IN 8 IN —
MY8-AD96
MY8-DA96 ANALOG OUT —
8 OUTMY8-AE96S
AES/EBU 8 IN
MY8-AE96
MY16-AT ADAT
16 IN 16 OUTMY16-AE AES/EBU
MY16-TD TASCAM
MY16-C CobraNet ™ 16 IN 16 OUT
