Yamaha RX-V577 - Channel System

PREPARATIONS ➤ Placing speakers En 13
7.1-channel system (RX-V577 only)
6.1-channel system (RX-V577 only)
5.1-channel system
5.1-channel system (Virtual CINEMA FRONT)
• To utilize this configuration, set "Virtual CINEMA FRONT" (p.78) in the "Setup" menu to "On".
• You can enjoy surround sound even without the center speaker (front 4.1-channel system).
