62

MIDE

MODE

In

this

example,

the

RX5

is

part

of

a

sophisticated

digital!

music

system

comprising

a

0х?

synthesizer,

a

QX5

sequence

recorder,

and

a

TX816

FM

tone

generator

system.

An

MJC8

MIDI

junction

controller

enables

instant

switching

between

a

wide

variety

of

MIDI

setups,

to

make

full

use

of

the

RX5's

versatility.

е

The

RX5

can

be

controlled

by

the

QX5

sequence

recorder

in

two

ways:

(1)

by

receiving

stop/start

messages

and

clack

signals

to

control

its

tempo

(refer

to

JOB

#01)

or

(2)

by

receiving

actual

note

information

—the

drum

part

would

be

stored

in

the

QX5

instead

of

in

the

RX5's

data

memory)

—

refer

to

JOB

#08.

è

The

RX5's

instrument

sounds

can

be

played

by

the

DX7

in

two

ways:

(1)

by

assigning

each

instrument

on

the

RX5

to

a

note

on

the

DX7,

so

that

complete

rhythm

patterns

could

be

played

and

recorded

from

the

keyboard

(refer

to

JOB

#04

—

Note

Number

Mode)

or

(2)

by

using

the

Tunable

Note

function,

enabling

the

DX7

to

play

one

of

the

HX5's

voices

over

the

entire

range

of

its

keyboard

(refer

to

JOB

#04

—

Tunable

Note

Mode).

è

Тһе

RX5

can

act

as

a

type

of

sequencer,

sending

note

data

(including

Note

ОН

messages)

on

independent

MIDI

channels

to

the

DX7

and

to

each

module

in

the

TX816

(refer

to

JOB

#03).

THE

JOBS

Job

#01:

CHANNEL

MESSAGE.

Set

the

ҢХ5

to

receive

and

transmit

MIDI

messages.

Job

#02:

RECEIVE

CHANNEL.

Set

the

MIDI

channel(s)

on

which

the

RXS

receives

MIDI

messages.

Job

#03:

TRANSMIT

CHANNEL.

Assign

each

instrument

to

one

of

the

16

available

MIDI

channels,

for

transmission.

Job

#04:

NOTE

NUMBER

ASSIGN.

Assign

the

RX5's

voices

to

a

selected

MIDI

note

number,

for

MIDI

receive

and

transmit

(Note

Number

Mode).

Also

assign

one

voice

to

each

of

the

16

MIDI

channels

to

use

as

sound

source

for

external

device

(Tunable

Note

Mode).

Job

#05:

INITIALIZE

NOTE.

Return

the

MIDI

note

number

settings

of

all

64

instruments

of

the

RX5

to

their

default

settings.

Job

#06:

E.G.

VELOCITY.

Set

the

amount

by

which

envelope

parameters

can

be

affected

by

the

velocity

of

an

external

MIDI

device.

Job

#07:

GATE

TIME.

Set the

length

of

the

Gate

Time

transmitted

by

the

RX5

to

external

MIDI

devices.

Job

#08:

DEVICE

NUMBER.

Set

the

RX5

to

receive

or

transmit

System

Exclusive

Information,

on

a

selected

MIDI

channel.

Job

#09:

RECEIVE

BULK.

Send

a

Bulk

Dump

Request

to

an

externa!

MIDI

device.

Job

#10:

TRANSMIT

BULK.

Transmit

Bulk

data

to

an

external

MIDI

device.

ENTERING

THE

MIDI

MODE

To

enter

the

MIDI

Mode,

press

the

MIDI

key.

The

MIDI

LED

will

light.

The

LCD

will

show

the

last

Job

that

was

selected

in

this

Mode.

Now,

or

after

using

any

MIDI

Mode

function,

press

any

Mode

key,

or

the

PATTERN/

SONG

key,

to

exit

this

Mode.

Jobs

are

selected

by

pressing

the

JOB

key

(after

pressing

the

MIDI

key)

then

entering

the

Job

number

using

the

10-key

panel.

Once

in

this

Mode,

there

is

no

need

to

press

the

MIDI

key

prior

to

selecting

other

Jobs.

JOB

#01:

CHANNEL

MESSAGE

FUNCTION

roenabie

reception/transmission

of

Note

Number

messages.

This

function

lets

you

control

the

RX5

from

an

external

MIDI

device

(reception

of

MIDI

data)

or

use

the

RX5

to

control

an

external

MIDI

device

(transmission

of

MIDI

data).

NOTE:

The

MIDI

Receive

and/or

MIDI

Transmit

channels

must

be

set

to

match

the

MIDI

channel

of

the

external

MIDI

device.

Refer

to

Jobs

#02,

#03

respectively.

OPERATION

1.

Press

MIDI

and

select

Job

#01.

The

LCD

will

show

the

current

ON/OFF

status

of

this

Job.

|

MIDI

INFORMATION

Ch

Message

OFFE

2.

Press

—

1/NO

ог

+

1/YES

to

turn

the

Channel

Mode

Message

OFF

or

ON

respectively.

JOB

#02:

RECEIVE

CHANNEL

FUNCTION

тота

on

or

off

each

of

the

16

MIDI

Channels,

for

reception

of

MIDI

control

signals

from

external

MIDI

devices.

This

Job

is

related

to

Job

#04,

NOTE

NUMBER

ASSIGN.

If,

in

Job

#04,

you

have

selected

“VOICE”,

the

RX5

is

now

set

to

the

Note

Number

Made.

In

this

Mode

the

RX5

can

receive

MIDI

control

signals

on

any

one

of

the

16

available

MIDI

Channels.

If,

in

Job

#04,

you

have

selected

"PITCH",

the

RX5

is

now

set

to

the

Tunable

Note

Mode.

In

this

Mode,

the

RX5

can

receive

MIDI

control

signals

оп

any

or

all

of

the

16

available

MIDI

channels.

Each

channel

will

have

an

RX5

voice

assigned

to

it

(also

using

JOB

#04).
