2. PRE-OPERATION PROCEDURES
Installation Procedures
22. Close lid.
Rotate lid pivot arm to the right until it interlocks
with stop block and cannot be rotated further.
Turn handle clockwise in 1/4-1/2 turns until lid is
sealed securely. Do not overtighten. If lid is not
closed completely, steam will escape from the
chamber and contents will not be sterilized
properly. Be sure that end of pivot arm is
completely inserted into stop block and that lid
has a good seal.
23. Position the condensation trap.
Place the condensation trap cup into the
magnetic holder and position under the steam
condensation outlet, to catch condensation
buildup so it does not drip onto the floor. See
illustration to the right.
CLOSE
Lid
Pivot Arm
Handle
Stop Block
