1.21 Defaults by Drive Model and Duty Rating ND/HD
138 YASKAWA TOEPYAIGA5002A GA500 DRIVE PROGRAMMING
No.
*1
Name Unit Default
- Drive Model - 4001 4002 4004 4005
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 91 92 93 94
E2-11
(E4-11, E5-
02)
Motor Rated
Power
kW 0.2 0.4 0.4 0.75 0.75 1.5 1.5 2.2
E2-02
(E4-02)
Motor Rated
Slip
Hz 2.5 2.9 2.9 2.6 2.6 2.5 2.5 3
E2-03
(E4-03)
Motor No-
Load Current
A 0.4 0.6 0.6 0.8 0.8 1.4 1.4 1.5
E2-05
(E4-05)
Motor Line-to-
Line
Resistance
Ω 83.94 38.198 38.198 22.459 22.459 10.1 10.1 6.495
E2-06
(E4-06)
Motor
Leakage
Inductance
% 21.9 18.2 18.2 14.3 14.3 18.3 18.3 18.7
E2-10
(E4-10)
Motor Iron
Loss
W 12 14 14 26 26 53 53 77
E5-01
PM Motor
Code Selection
- FFFF FFFF FFFF FFFF FFFF FFFF FFFF FFFF
L2-02
Power Loss
Ride Through
Time
s 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
L2-03
Minimum
Baseblock
Time
s 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 380 380 380 380 380 380 380 380
L3-02
Stall Prevent
Level during
Accel
% 150 120 150 120 150 120 150 120
L3-06
Stall Prevent
Level during
Run
% 150 120 150 120 150 120 150 120
L3-24
Motor Accel
Time @ Rated
Torque
s 0.178 0.178 0.178 0.142 0.142 0.166 0.166 0.145
L8-02
Overheat
Alarm Level
°C 120 120 120 120 105 105 90 90
L8-09
Output Ground
Fault
Detection
- 0 0 0 0 0 0 0 0
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n3-02
HSB Current
Limit Level
% 150 120 150 120 150 120 150 120
n5-02
Motor Inertia
Acceleration
Time
s 0.178 0.178 0.178 0.142 0.142 0.166 0.166 0.145
*1 Parameters within parentheses are for motor 2.
