Explanation of Warning Labels
viii
157569-1CD
HW0485652
MPL100
Explanation of Warning Labels
The following warning labels are attached to the manipulator.
Always follow the warnings on the labels.
Also, an identification label with important information is placed on the
body of the manipulator. Prior to operating the manipulator, confirm the
contents.
Figure 3: Warning Label Locations
WARNING label A
WARNING label B
Nameplate
WARNING
Moving parts
may cause
injury
WARNING Label A:
WARNING Label B:
Nameplate
WARNING
Do not enter
robot
work area.
WARNING
Do not enter
robot
work area.
MADE IN JAPAN
YASKAWA ELECTRIC CORPORATION
Kitakyushu 806-0004 Japan
2-1 Kurosakishiroishi, Yahatanishi-ku,
SERIAL NO.
PAYLOAD
kg
TYPE
MASS
DATE
ORDER NO.
kg
MOTOMAN-
MODEL
