4.5 Board Dimensions

73 mm

90 mm

11 mm

7.85 mm

18.85 mm

94.8 mm

Sigma-5 and Sigma-7 Series SERVOPACKs

Specifications

Board Dimensions

| | Feedback Option Module Type 3 - Manual version C - Revision 0 | en | 34
