7. Now snap on the cover for the network module to the SERVOPACK, the completed
unit will look like the following picture.
5.4 EMC Installation Conditions
This section gives the installation conditions that were used for EMC certification testing.
The EMC installation conditions that are given here are the conditions that were used to
pass testing criteria at Yaskawa. The EMC level may change under other conditions, such
as the actual installation structure and wiring conditions. These Yaskawa products are
designed to be built into equipment. Therefore, you must implement EMC measures and
confirm compliance for the final equipment.
The applicable standards are EN 55011 group 1 class A, EN 61000-6-2, EN 61000-6-4,
and EN 61800-3 (category C2, second environment).
Sigma-5 and Sigma-7 Series SERVOPACKs
Hardware Installation
EMC Installation Conditions
| | Feedback Option Module Type 3 - Manual version C - Revision 0 | en | 40
