— C-3 —
RemarksFactory
Setting
Upper
Limit
Lower
Limit
UnitNameCodeParameter
No.
Category
Other
Constants
Cn-0C TRQMSW Mode switch
(torque
reference)
% 0 Maximum
torque
200
Cn-0D REFMSW Mode switch
(speed
reference)
min
−1
0 Maximum
speed
0
Cn-0E ACCMSW Mode switch
(acceleration
reference)
10
(min
−1
)/s
0 3000 0
Cn-10 JOGSPD Jog speed min
−1
0 Maximum
speed
500
Cn-1F SPEED1 1st speed
(contact input
speed control)
min
−1
0 Maximum
speed
100
Cn-20 SPEED2 2nd speed
(contact input
speed control)
min
−1
0 Maximum
speed
200
Cn-21 SPEED3 3rd speed
(contact input
speed control)
min
−1
0 Maximum
speed
300
Cn-28 NFBCC Speed loop
compensation
constant
--- 0 100 0
Cn-29 AXISNO Axis address --- 0 14 0
Cn-2A INS1 Input signal
selection 1
--- 0 3 0 See note 1
Cn-2B INS2 Input signal
selection 2
--- 0 3 2 See note 1
Cn-2C OUTS2 Output signal
selection 2
--- 0 4 3 See note 1
Note 1) After changing the setting, always turn OFF the power, then turn ON again to validate
the new settings.
2) Automatically set by autotuning function.
3) Valid only when zero-clamp function is used.
4) To use soft start function, always set both Cn-07 and Cn-23.
C
