Yealink SIP-T42S User Manual

User Guide for the SIP-T42S IP Phone
102
When DND feature is activated, the IP phone supports displaying a large DND icon on the idle
screen. For more information, contact your system administrator.
You can activate/deactivate DND for the phone system, or you can customize DND for each or
all accounts.
There are two DND modes:
 Phone (default): DND is effective for the phone system.
 Custom: DND can be configured for each or all accounts
To configure the DND mode via web user interface:
1. Click on Features->Forward&DND.
2. In the DND block, mark the desired radio box in the Mode field.
3. Click Confirm to accept the change.
Note
To activate DND in phone mode:
1. Press the DND soft key when the phone is idle.
The icon appears on the status bar.
Note
DND mode is configurable via web user interface only.
When DND and busy forward are activated in phone mode, calls will be sent to the configured
destination number. For more information on busy forward, refer to Call Forward on page 105.

Yealink SIP-T42S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Lines quantity	12 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.723.1, G.726, G.729ab, VAD, iLBC
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	2.7 \
Display resolution	192 x 64 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	6
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS

Weight and Dimensions

Depth	189 mm
Width	212 mm
Height	175 mm
Package depth	223 mm
Package width	246 mm
Package height	120 mm
