Configuring Call Preferences
105
SIP IP call parameters on the system are described below:
Enables or disables the SIP IP Call.
Default: Enabled.
Note: When it is set to Enabled on
both sites, the VC800 can call the far
site by dialing an IP address directly.
Remote Control
Web User Interface
Configures the type of transport
protocol for the SIP IP call.
UDP—provides best-effort
transport via UDP for SIP
signaling.
TCP—provides reliable
transport via TCP for SIP
signaling.
DNS-NAPTR—performs the
DNS NAPTR and SRV queries
for the service type and port if
no server port is given.
Default: TCP
Remote Control
Web User Interface
To configure SIP IP call via web user interface:
1. Click on Account->SIP IP Call.
2. Select the desired value from the pull-down list of SIP IP Call.
3. Select the desired value from the pull-down list of Transport.
4. Click Confirm to accept the change.
