Yealink W60B Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK W60B IP DECT PHONE 20-BD5561-00
©
2018 BROADSOFT INC. PAGE 18 OF 117
4 W60B IP DECT PHONE Configuration
This section describes the configuration settings required for the W60B IP DECT PHONE
integration with BroadWorks, primarily focusing on the SIP interface configuration. The
W60B IP DECT PHONE configuration settings identified in this section have been derived
and verified through interoperability testing with BroadWorks. For configuration details not
covered in this section, see the Yealink W60B IP DECT PHONE User Guide [1].
4.1 Configuration Method
The capabilities of the W60B IP DECT PHONE have been verified for use with
BroadWorks based on the settings described in the following table. For more information
on the meaning, purpose, and applicability of the individual configuration items see the
Yealink W60B IP DECT PHONE User Guide [1].
Configuration Files
Files Provided by Partner Level Description
y0000000000<xx>.cfg system configuration file “y0000000000xx.cfg”, where “xx”
is associated with the hardware
version of Yealink Device.
<MACADDRESS>.cfg device-specific
configuration file
Device specific account
information file.
4.2 System Level Configuration
This section describes system-wide configuration items that are generally required for
each W60B IP DECT PHONE to work with BroadWorks. Subscriber-specific settings are
described in the next section.
Step Command Purpose
System Configuration Items y0000000000<xx>.cfg
Step 1
Set SIP Proxy/Domain.
account.1.sip_server_host =
as.broadworks.net
account.1.SIPServerPort = 5060
account.1.sip_server_type = 2
Set the W60B IP DECT PHONE SIP
server to the Fully Qualified Domain
Name (FQDN) for the BroadWorks
Application Server cluster.
The domain must match the domain
configured for the BroadWorks
subscriber’s line/port domain.
Set the SIP server type of W60B:
Default=0
BroadSoft=2
Step 2
Set Outbound Proxy.
account.1.outbound_proxy_enable =
1
account.1.outbound_host =
sbc.broadworks.net
account.1.outbound_port = 5060
Set the Outbound Proxy to the
session border controller (SBC) if one
is deployed between the W60B IP
DECT PHONE and BroadWorks.
If there are redundant SBCs, set it to
the FQDN for the SBC cluster.
Step 3
Set SIP Timers.
sip.timer_t1 = 0.5
sip.timer_t2 = 4
sip.timer_t4 = 5
The SIP timers should be set to levels
short enough to support a timely
failover when there is no server
response.

Yealink W60B Specifications

General

Dimensions	130mm x 100mm x 25.1mm
Operating Temperature	0°C to +40°C
DECT Standards	CAT-iq 2.0
Number of Handsets	Up to 8
Internal Calls	Yes
External Calls	Yes
Call Hold	Yes
Call Transfer	Yes
3-way Conference	Yes
Call Waiting	Yes
Mute	Yes
Redial	Yes
DECT Radio Coverage	Up to 50m indoors, 300m outdoors
PoE	IEEE 802.3af Class 1
Configuration	Browser/phone/auto-provision
Wall Mountable	Yes
Wireless Technology	DECT
Channels	120
Concurrent Calls	Up to 8 concurrent calls
Audio Codecs	G.722, G.711, G.729, G.726, iLBC, Opus
Security	TLS, SRTP, HTTPS, 802.1X
Operating Humidity	10 ~ 95%
Handset Registration	8 handsets
Frequency Bands	1880-1900 MHz
Operating Range	Up to 50m indoors, 300m outdoors
Humidity	10-95%
Compliance	CE, FCC, RCM
Network Protocols	SIP, HTTP, HTTPS, DHCP, DNS, NTP, STUN
Number of SIP Accounts	Up to 8 SIP accounts
Storage Temperature	-30°C to +70°C
