Yealink W60B Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK W60B IP DECT PHONE 20-BD5561-00
©
2018 BROADSOFT INC. PAGE 20 OF 117
Step Command Purpose
Subscriber parameters for the <MACADDRESS>.cfg
Step 3
S]=et Register User ID for a
line.
Example:
account.1.user_name = 2405551111
The register user ID must
correspond with the line/port
setting on BroadWorks.
Step 4
Enable SIP Authentication for a
line.
Example:
account.1.auth_name = 2405551111
account.1.password = 123456
If the Authentication service is
configured on BroadWorks, these
parameters must be configured to
match the BroadWorks settings.
Step 5
Configure Network Phonebook.
account.1.xsi.host =
xsp1.iop1.broad works.net
account.1.xsi.user =
2413333601@as.iop1.
broadworks.net
account.1.xsi.password = yealink
This configures the phone to use
the BroadWorks Xsi interface to
retrieve the group phone directory.
Host: This is the identity of the
BroadWorks Xsp server/cluster
address and relevant xsi-actions
parameters.
User: This is the BroadWorks
user’s login name.
Password: This is the BroadWorks
user’s login password.
4.4 SIP Advanced Feature Configuration
This section provides configuration instructions for advanced SIP features supported by
the phone including but not limited to Shared Call Appearance, Busy Lamp Field, Feature
Key Synchronization, Call Center, and Emergency Call.
4.4.1 Shared Call Appearance Configuration
The Shared Call Appearance (SCA) feature allows the administrator to add multiple
locations to a given line. Any of the locations can be used to originate or receive calls.
When a call comes in to an idle line, all the provisioned locations for that line are alerted.
The first location to answer the call is connected to the originator. If the line is already
active in a call, only the active location is alerted.
A subscriber can originate calls from any of the configured locations. All other locations
are unable to originate calls until all calls are released.
It is recommended that the phone number plus an index (<phoneNumber>_<index>) is
used when provisioning the unique address of record (AoR) for each shared line. For
example: 2405551111_2. If a phone number does not exist, the MAC address plus an
index could be used (<macAddress>_<index>).

Yealink W60B Specifications

General

Dimensions	130mm x 100mm x 25.1mm
Operating Temperature	0°C to +40°C
DECT Standards	CAT-iq 2.0
Number of Handsets	Up to 8
Internal Calls	Yes
External Calls	Yes
Call Hold	Yes
Call Transfer	Yes
3-way Conference	Yes
Call Waiting	Yes
Mute	Yes
Redial	Yes
DECT Radio Coverage	Up to 50m indoors, 300m outdoors
PoE	IEEE 802.3af Class 1
Configuration	Browser/phone/auto-provision
Wall Mountable	Yes
Wireless Technology	DECT
Channels	120
Concurrent Calls	Up to 8 concurrent calls
Audio Codecs	G.722, G.711, G.729, G.726, iLBC, Opus
Security	TLS, SRTP, HTTPS, 802.1X
Operating Humidity	10 ~ 95%
Handset Registration	8 handsets
Frequency Bands	1880-1900 MHz
Operating Range	Up to 50m indoors, 300m outdoors
Humidity	10-95%
Compliance	CE, FCC, RCM
Network Protocols	SIP, HTTP, HTTPS, DHCP, DNS, NTP, STUN
Number of SIP Accounts	Up to 8 SIP accounts
Storage Temperature	-30°C to +70°C
