Yealink W60B Configuration Guide

BROADSOFT PARTNER CONFIGURATION GUIDE – YEALINK W60B IP DECT PHONE 20-BD5561-00
©
2018 BROADSOFT INC. PAGE 23 OF 117
Step Command Purpose
Step 4
Configure display name.
Example:
account.1.Display_Name = Joe Brown;
Configure the name to be
displayed on the device for this
line.
The following steps are used to configure line 2 for Joe’s phone. This line rings when Bob
is called, so it has Bob’s authentication information.
Step Command Purpose
Step 1
Configure line as shared.
account.2.shared_line = 1;
Configure the line as “shared”
(as opposed to “private”).
Step 2
Set Register User ID.
Example:
account.2.user_name = 2405552222_2;
The register user ID must
correspond with the line/port
setting on BroadWorks.
Step 3
Enable SIP Authentication.
Example:
account.2.Auth_Name = bobsmith;
account.2.password password = bobs;
If the Authentication service is
configured on BroadWorks,
these parameters must be
configured to match the
BroadWorks settings.
This line rings when Bob is
called, so it has Bob’s
authentication information.
Step 4
Configure display name.
Example:
account.2.Display_Name = Bob Smith;
Configure the name to be
displayed on the device for this
line.
4.4.1.3 Hybrid Key System Configuration
Yealink W60B IP DECT PHONE does not support Hybrid Key System.
4.4.2 Busy Lamp Field Configuration
Yealink W60B IP DECT PHONE does not support Busy Lamp Field.
4.4.3 Feature Key Synchronization Configuration
Feature Key Synchronization provides synchronization of phone services such as Call
Forwarding and Do Not Disturb with the settings on BroadWorks for the analogous
services. Configure the phone to enable Feature Key Synchronization as follows:
Step Command Purpose
Step 1
Enable Feature Key Synchronization.
Example:
features.feature_key_sync.enable = 1
Enable Feature Key
Synchronization feature.
 0 for Disabled
 1 for Enable
Browse to Features → General Information and set Feature Key Synchronization to
“Enabled”.

Yealink W60B Specifications

General

Dimensions	130mm x 100mm x 25.1mm
Operating Temperature	0°C to +40°C
DECT Standards	CAT-iq 2.0
Number of Handsets	Up to 8
Internal Calls	Yes
External Calls	Yes
Call Hold	Yes
Call Transfer	Yes
3-way Conference	Yes
Call Waiting	Yes
Mute	Yes
Redial	Yes
DECT Radio Coverage	Up to 50m indoors, 300m outdoors
PoE	IEEE 802.3af Class 1
Configuration	Browser/phone/auto-provision
Wall Mountable	Yes
Wireless Technology	DECT
Channels	120
Concurrent Calls	Up to 8 concurrent calls
Audio Codecs	G.722, G.711, G.729, G.726, iLBC, Opus
Security	TLS, SRTP, HTTPS, 802.1X
Operating Humidity	10 ~ 95%
Handset Registration	8 handsets
Frequency Bands	1880-1900 MHz
Operating Range	Up to 50m indoors, 300m outdoors
Humidity	10-95%
Compliance	CE, FCC, RCM
Network Protocols	SIP, HTTP, HTTPS, DHCP, DNS, NTP, STUN
Number of SIP Accounts	Up to 8 SIP accounts
Storage Temperature	-30°C to +70°C
