FXO Trunk:
Status
Idle: The port is idle.
Busy: The port is in use.
Disconnected: The port hasn‟t connected the PSTN line.
More detail message, please refer to the LED identifying of front panel.
GSM Trunk:
Status
Idle: The port is idle.
Busy: The port is in use.
Signal
: No signal.
: Poor.
: Average.
: Good.
: Excellent.
BRI Trunk:
Status
Ok: The ports connect correctly.
Disconnected: The port hasn‟t connected the PSTN line.
Service Provider:
Status
OK: Succeed registration, trunk is ready for use.
Unreachable: The trunk is unreachable.
Failed: Trunk registration failed.
3.3 Basic
3.3.1 Extension
Extension has two types: Analog extensions (FXS) and VOIP extensions (SIP
extension or IAX extension).
