1-22
IM CA500-01EN
Saving Data Using Step Sweep
Saved data Notes
MODEL CA550
FILE TYPE 0: Manually saved data using the SAVE key
1: Automatically saved data by a step sweep
2: Calibration data by a program sweep
CSV SEPARATOR 0: Comma, 1: Semicolon, 2: Tab
DECIMAL POINT 0: Period, 1: Comma
DATE FORMAT 0: YYYY/MM/DD
1: DD/MM/YYYY
2: MM/DD/YYYY
Range Measurement range, source range
0% VALUE
100% VALUE
DIVISION NUMBER (number of
divisions)
CONTACT (contact I/O) 0: OFF, 1:ON
TC SETTING
(temperature setting)
Thermocouple terminal setting. 0: TC-A, 1: TC-B
TC-B RJC setting. 0: OFF, 1:ON
Burnout setting. 0: OFF, 1:ON
TC scale standard setting. 0: ITS-90, 1:IPTS-68
Temperature unit. 0: °C
FREQUENCY SETTING
(frequency setting)
Amplitude voltage setting
Pulse count setting
No. Number
DATE Measurement date YYYY/MM/DD
TIME Measurement time hh:mm:ss
MEASURE Measured value
SOURCE Source value
1.7 Saving and Loading CA550 Data
