YOKOGAWA CA500 User Manual

1-23
Features
IM CA500-01EN
1
2
3
4
5
6
7
Index
Saving Data Using Program Sweep
Saved data Notes
MODEL CA550
FILE TYPE 0: Manually saved data using the SAVE key
1: Automatically saved data by a step sweep
2: Calibration data by a program sweep
CSV SEPARATOR 0: Comma, 1: Semicolon, 2: Tab
DECIMAL POINT 0: Period, 1: Comma
DATE FORMAT 0: YYYY/MM/DD
1: DD/MM/YYYY
2: MM/DD/YYYY
Range Measurement range, source range
0% VALUE
100% VALUE
CONTACT (contact I/O) 0: OFF, 1:ON
TC SETTING
(temperature setting)
Thermocouple terminal setting. 0: TC-A, 1: TC-B
TC-B RJC setting. 0: OFF, 1:ON
Burnout setting. 0: OFF, 1:ON
TC scale standard setting. 0: ITS-90, 1:IPTS-68
Temperature unit. 0: °C
FREQUENCY SETTING
(frequency setting)
Amplitude voltage setting
Pulse count setting
MODEL NO. Model number
TAG NO. Tag number
SERIAL NO. Serial number
CALIBRATION DATE Calibration date
YYYY/MM/DD
CALIBRATOR S/N CA550 serial number
No. Calibration point number
DATE Calibration date YYYY/MM/DD
TIME Calibration time of the calibration point hh:mm:ss
MEASURE Measured value
SOURCE Source value
ERROR% Error
PASS/FAIL Pass/fail
Loading Data
Only the data saved using program sweep can be loaded.
Folder Structure
The following figure shows the CA550 folder structure.
Root
SaveData
SweepData
CalibrationData
Data saved with the SAVE key is saved.
Measurement/source data (.csv) of program
sweeps is saved.
Measurement/source data (.csv) of step
sweeps is saved.
1.7 Saving and Loading CA550 Data
