6.2 General Settings 1/2
6.2.2 Setting Up the Number of Loads
TOP
MENU
ENTER
ENTER
LIGHT
TOP
MENU
SAVE
A
RANGE
START
&STOP
ESC
ENTER
F 1
F 2 F 3 F 4 F 5
DISP COPY
RANGE
[ 1 Displaying the General 1/2 screen
Using the right and left cursor keys, select the General tab
(highlighted).
[ 2 Changing the number of loads
Using the up and down cursor keys, select LOAD (highlighted).
The function key labels change.
LOAD1 LOAD2 LOAD3 LOAD4
F 1 F 1
F 2
F 3
F 4
F 5
Default: LOAD1
[ 3 Setup
F 1 F 1
to
F4
Press the corresponding function key to set the number of loads.
Ending setup:
To also change another setting To return to the Top Menu
Select a desired setting using the cursor keys. ENTER key
