YOKOGAWA CW240 User Manual

6-7
IM CW240E
Configuring Settings
6
6.2 General Settings 1/2
[ 1 Displaying the General 1/2 screen
Using the right and left cursor keys, select the General tab
(highlighted).
[ 2 Changing Wiring
Using the up and down cursor keys, select WIRING (highlighted).
[ 3 Displaying the window
F 1 F 1
Press the F1 key (CHANGE).
The window for selecting wiring appears.
3P3W+1P3W
3P4W4I
3P4W
3P3W3I
3P3W2I
1P3W3I
1P3W
1P2W
Scott connection
Three-phase four-wire four-current
Three-phase four-wire
Three-phase three-wire three-current
Three-phase three-wire two-current
Single-phase three-wire three-current
Single-phase three-wire
Single-phase two-wire
Default: 3P3W2I
[ 4 Selecting wiring
Using the cursor keys, select a desired wiring (highlighted).
To cancel changing the setting, press the ESC key. The window returns to
the General screen.
[ 5 Confirmation
ENTER
Press the ENTER key.
This closes the window, returning you to the General screen.
The selected wiring is displayed on the screen.
Ending setup:
To also change another setting To return to the Top Menu
Select a desired setting using the cursor keys. ENTER key
