YOKOGAWA CW240

6-15
IM CW240E
Configuring Settings
6
[ 2 Changing a clamp-on probe
Using the up and down cursor keys, select CLAMP (highlighted).
The function key labels change.
[ 3 Displaying the window
F 1 F 1
Press the F1 key (CHANGE).
The window for selecting a clamp-on probe appears.
96035_2
96035_1
96034_3
96034_2
96034_1
96032
96031
96030
96033
96036
Default: 96030
[ 4 Selecting a clamp-on probe
Using the cursor keys, select the model of a clamp-on probe
(highlighted).
To cancel changing the setting, press the ESC key. The window returns to
the General screen.
[ 5 Confirmation
ENTER
Press the ENTER key.
This closes the window, returning you to the General screen. The selected
clamp-on current probe is displayed on the screen.
Ending setup:
To also change another setting To return to the Top Menu
Select a desired setting using the cursor keys. ENTER key
6.2 General Settings 1/2
