Using Analog Input/Output (Optional)
13
13.1.2 Analog Output Setting Items
Items that can be set as output are given in the following table.
Item Element Order Magnification Output Rate
NORMAL
Voltage (U1, U2, U3, Uave)
Current (I1, I2, I3, I4, Iave)
Power (P)
Reactive power (Q)
Apparent power (S)
Power factor (PF)
Phase angle (PA)
Frequency (F)
E. ENERGY
E. ENERGY Active energy (Wh+)
Regenerative energy (Wh-)
Lagging reactive energy (Varh+)
Leading reactive energy (Varh-)
LEVEL
Voltage (U1, U2, U3)
Current (I1, I2, I3, I4)
Power (P)
1 to 50
1, 10, and 100
times
_
CONTENT
Voltage (U1, U2, U3)
Current (I1, I2, I3, I4)
Power (P)
1 to 50
1, 10, and 100
times
_
HARM. PA
Voltage (U1, U2, U3)
Current (I1, I2, I3, I4)
Power (P)
1 to 50 _ _
TOTAL VAL
Voltage (U1, U2, U3)
Current (I1, I2, I3, I4)
Power (P)
__ _
THD
Voltage (U1, U2, U3)
Current (I1, I2, I3, I4)
__ _
__
__
1V/1kWh
1V/5kWh
1V/10kWh
1V/50kWh
1V/100kWh
1V/500kWh
1V/1000kWh
_
Harmonics
NOTE
• Analog output items that can be set vary depending on the wiring.
• For measurement of multiple loads, analog output items can be selected on a
load basis. A number representing load(s) is appended following each ele-
ment (e.g., I1_1, I1_2, P_1, and P_2).
• For Scott connections, a symbol representing which load is applied is ap-
pended following each element (e.g., U1_3P, U1_1P, P_3P, and P_1P).
