YOKOGAWA DL9040 User Manual

2-2
IM 701310-17E
2.2 Ethernet/VXI-11 Interface Features and
Specifications
Ethernet/VXI-11 Interface Features
Reception Feature
The DL9000 reception feature allows you to specify the same settings through an
Ethernet connection that you can specify using the front panel keys.
The DL9000 can receive output requests for measured and computed data, panel setting
data, and error codes.
Transmission Feature
The DL9000 can transmit measured and computed data.
The DL9000 can transmit panel setting data and the status byte.
The DL9000 can transmit error codes when errors occur.
Ethernet/VXI-11 Interface Specifications
Electrical and mechanical
specifications
IEEE802.3 compliant
Simultaneous connections 1
Port number
Ethernet: 10001/tcp
VXI-11: 10240/tcp, 10250/tcp, 111/tcp, and 111/udp
Data Transfer Rates
The response time when outputting waveform data is shown below as a reference.
Model: 701313 main unit
Controller: PC (Pentium4 3.4 GHz) and OS (Windows XP Professional SP1)
Network adapter: Corega FEther PCI-TXL
Language used: Visual C++
Ethernet Interface (/C8, /C9, /C10 and /C12 options)
Number of Data Points Word Data ASCII Data
2500 Approx. 16 ms Approx. 0.391 s
125000 Approx. 259 ms Approx. 19.063 s
1250000 Approx. 2313 ms Approx. 189.812 s
2500000 Approx. 4595 ms Approx. 379.750 s
6250000 Approx. 10400 ms Approx. 950.532 s
VXI-11 Ethernet Interface (/C8, /C9, /C10 and /C12 options)
Number of Data Points Word Data ASCII Data
2500 Approx. 31 ms Approx. 0.406 s
125000 Approx. 235 ms Approx. 19.172 s
1250000 Approx. 2286 ms Approx. 191.876 s
2500000 Approx. 4541 ms Approx. 383.012 s
6250000 Approx. 1
1150 ms Approx. 958.128 s
