3-4
IM 701310-17E
3.4 GP-IB Interface Specifications
GP-IB Interface Specifications
Electrical and mechanical specifications: Conforms to IEEE St’d 488-1978
Functional specifications: See table below.
Protocol: Conforms to IEEE St’d 488.2-1992
Code used: ISO (ASCII) code
Mode: Addressable mode
Address setting: The address can be set in the range from 0
to 30 on the GP-IB setting screen that is
played using the MISC menu.
Clear remote mode: Remote mode can be cleared by pressing
CLEAR except when the DL9000 has been
set to Local Lockout mode by the controller.
Functional specifications
Function Subset Name Description
Source handshaking SH1 Full source handshaking capability
Acceptor handshaking AH1 Full acceptor handshaking capability
Talker T6 Basic talker capability, serial polling, untalk on MLA
(My Listen Address), and no talk-only capability
Listener L4 Basic listener capability, unlisten on MTA (My Talk
Address), and no listen-only capability.
Service request SR1 Full service request capability
Remote local RL1 Full remote/local capability
Parallel polling PP0 No parallel polling capability
Device clear DC1 Full device clear capability
Device trigger DT0 No device trigger capability
Controller C0 No controller capability
Electrical characteristics E1 Open collector
Data Rate
The response time when outputting waveform data is shown below as a reference.
Model: 701313
Controller: PC (Pentium4 3.4 GHz, USB 2.0), OS (Windows XP Professional SP1)
Language used: Visual C++
Number of Data Points Word Data ASCII Data
2s500 Approx. 16 ms Approx. 0.390 s
125000 Approx. 344 ms Approx. 19.453 s
1250000 Approx. 3172 ms Approx. 194.516 s
2500000 Approx. 6282 ms Approx. 389.047 s
6250000 Approx. 15641 ms Approx. 971.985 s
