Appendix 4 Eye Pattern Parameter Name Table
Name Displayed on
the Setup Menu of the
DL9000 Screen
Name Used by
Communication Commands
Name on the DL9000 Screen When
Displaying Measured Results
Crossing % PCROssing Cross%
Eye Height EHEight EyeHi
Eye Width EWIDth EyeWid
Q Factor QFACtor QFact
Jitter JITTer Jitter
Duty Cycle Distriction % PDUTycycle DCDTime%
Vtop VTOP Vtop
Vbase VBASe Vbase
σ
top SDTop σtop
σbase SDBase σbase
T
crossing1 T1CRossing T
cros1
Tcrossing2 T2CRossing Tcros2
Vcrossing VCRossing Vcros
Ext Rate dB DBERate ERdB
Rise RISE Rise
Fall FALL Fall
