Appendix 2 Error Messages
This section describes the error messages related to communications.
• The messages can be displayed in English or Japanese on the DL9000. However,
when the messages are read from a PC or other similar computers, the messages are
displayed in English.
•
If servicing is required, contact your nearest
YOKOGAWA dealer for repairs.
• Only error messages related to communications are listed here. For other error
messages, see User’s Manual IM 701310-01E.
· Communication syntax error
· Communication execution error
· Model specific (other)
· Communication query error
· System error (communications)
100~199
200~299
300~398
400~499
399
Details given below.
Error in Communication Command (100-199)
Code Messages Corrective Action Reference Page
102 Syntax error. Invalid syntax. Chapter 4, 5
103 Invalid separator. Use a comma to separate the data. 4-1
104 Data type error. Write using the correct data form. 4-6 to 4-7
105 GET not allowed. GET is not supported for responses to interface messages. 3-6
108 Parameter not allowed. Check the number of data points. 4-6, Chapter 5
109 Missing parameter. Enter the required data. 4-6, Chapter 5
111 Header separator error. Use a space to separate the header and data. 4-1
112 Program mnemonic too long. Check the mnemonic (alphanumerical character string). Chapter 5
113 Undefined header. Check the header. 4-4, Chapter 5
114 Header suffix out of range. Check the header. 4-4, Chapter 5
120 Numeric data error. A number is required in the <NRf> form. 4-6
123 Exponent too large. Use a smaller exponent for <NR3> format. 4-6, Chapter 5
124 Too many digits. The value must be less than equal to 255 digits. 4-6, Chapter 5
128 Numeric data not allowed. Enter in a format other than <NRf> format. 4-6, Chapter 5
131 Invalid suffix. Check the unit of the <Voltage>, <Time>, <Frequency>, and
<Current>.
4-6
134 Suffix too long. Check the unit of the <Voltage>, <Time>, <Frequency>, and
<Current>.
4-6
138 Suffix not allowed. No units are allowed other than <Voltage>, <Time>,
<Frequency>, and <Current>.
4-6
141 Invalid character data. Select character data from the selections available in
{...|...|...}.
4-7, Chapter 5
144 Character data too long. Check the spelling of the character strings in {...|...|...}. 4-7, Chapter 5
148 Character data not allowed. Write in a data form other than {...|...|...}. 4-5, Chapter 5
150 String data error. Enclose <String> in double quotation or single quotation
marks.
4-7
151 Invalid string data. <String> is too long or contains characters which cannot be
used.
4-7, Chapter 5
158 String data not allowed. Enter in a data format other than <Character string>. 4-6, Chapter 5
161 Invalid block data. <Block data> is not allowed. 4-7, Chapter 5
168 Block data not allowed. <Block data> is not allowed. 4-7, Chapter 5
171 Invalid expression. Equations cannot be used. Chapter 5
178 Expression data not allowed. Equations cannot be used. Chapter 5
