YOKOGAWA DL9040 User Manual

App-4
IM 701310-17E
Appendix 3 Waveform Parameter Name Table
Name Displayed on
the Setup Menu of the
DL9000 Screen
Name Used by
Communication Commands
Name on the DL9000 Screen When
Displaying Measured Results
Max MAXimum Max
Min MINimum Min
High HIGH High
Low LOW Low
P-P PTOPeak P-P
Hi-Low HILow Hi-Low
+Over POVershoot +Over
-Over NOVershoot -Over
Rms RMS Rms
Mean MEAN Mean
Sdev SDEViation Sdev
IntegTY TYINteg ITY
C.Rms CRMS CRms
C.Mean CMEan CMean
C.Sdev CSDeviation CSdev
C.IntegTY TYCInteg CITY
Freq FREQuency Freq
1/Freq PERFrequency 1/FR
Count COUNt Count
Burst BURSt Burst
+Width PWIDth +Width
-Width NWIDth -Width
Period PERiod Period
Duty DUTYcycle Duty
Rise RISE Rise
Fall FALL Fall
Delay DELay Dly
