Explanation
The analysis results are stored in CSV format in the specified storage medium. The
extension is .CSV. A CSV-format data file is a comma-delimited, text-based file. It is one
common data format that is used for sharing data between different spreadsheet and
database applications.
A PC card, external USB device, or network drive (when the optional Ethernet interface is
installed) can be selected as the storage medium.
Data Type
Select one of the following three data types.
Wave Parameter: Saves the measured results for items specified for automatic
measurement of waveform parameters. (See section 10.2 and
section 10.3.)
Accum Histogram: Saves a histogram of the distribution frequency of the specified
region. (See section 10.9.)
FFT: Saves the results of the FFT
analysis. (See section 10.7.)
Wave Parameter
Saves the maximum number of data items (either 100,000/(the number of items set to
ON)) back from the point at which the save was executed.
• Data Size
Data size (bytes) = the number of measurement parameters × 15 × the number of
history waveforms
• Output example
Analysis Type WaveParameter
Model Name DL9000
Model Version *.**
Rms(C1) Mean(C1)
Sdev(C1) ITY(C1) CRms(C1) CMean(C1) CSdev(C1) Dly(C1) Calc1(A2)
V V V Vs V V V s
:Max 7.12E-01 5.05E-03
7.12E-01 5.05E-05 7.12E-01 5.33E-03 7.12E-01 1.13E-03 1.13E+00
:Min 7.10E-01 -4.44E-03
7.10E-01 -4.44E-05 7.10E-01 -4.46E-03 7.10E-01 -8.99E-04 1.08E+00
:Mean 7.11E-01 1.07E-03 7.11E-01 1.07E-05 7.11E-01 1.05E-03 7.11E-01 3.44E-04 1.10E+00
:Sigma 2.47E-04 2.04E-03
2.48E-04 2.04E-05 3.42E-04 2.11E-03 3.42E-04 9.68E-04 8.23E-03
:Cnt 134 134 134 134 134 134 134 134 134
7021 7.11E-01
2.29E-03 7.11E-01 2.29E-05 7.12E-01 2.33E-03 7.12E-01 1.11E-03 1.10E+00
7031 7.11E-01
1.43E-03 7.11E-01 1.43E-05 7.11E-01 1.41E-03 7.11E-01 1.11E-03 1.11E+00
7040 7.11E-01
3.51E-03 7.11E-01 3.51E-05 7.11E-01 3.01E-03 7.11E-01 1.11E-03 1.10E+00
7050 7.11E-01
1.73E-03 7.11E-01 1.73E-05 7.12E-01 1.86E-03 7.12E-01 1.11E-03 1.11E+00
7059 7.11E-01
1.80E-03 7.11E-01 1.80E-05 7.11E-01 1.99E-03 7.11E-01 -8.86E-04 1.11E+00
7069 7.11E-01
1.15E-03 7.11E-01 1.15E-05 7.11E-01 1.13E-03 7.11E-01 1.11E-03 1.10E+00
7078 7.11E-01
1.45E-04 7.11E-01 1.45E-06 7.11E-01 -1.77E-04 7.11E-01 -8.82E-04 1.12E+00
7088 7.11E-01
2.98E-03 7.11E-01 2.98E-05 7.11E-01 3.18E-03 7.11E-01 1.11E-03 1.10E+00
7098 7.11E-01
3.27E-03 7.11E-01 3.27E-05 7.10E-01 3.69E-03 7.10E-01 -8.92E-04 1.09E+00
7107 7.11E-01
3.12E-03 7.11E-01 3.12E-05 7.11E-01 2.92E-03 7.11E-01 -8.83E-04 1.12E+00
