17.1 Changing the Message Language, Menu

Language, and Font Size, and Turning ON/OFF

the Click Sound

Procedure

RESET

SET

7 8 9

FILE

SHIFT

SYSTEM

EXP

CLEAR

D E F X

k m

u n p

4 5 6

1 2 3

+/-

CA B

Press SYSTEM.

Press the MISC soft key.

Selecting the Message Language

Press the Message soft key to display the Message menu.

Press the ENG, JPN, CHN, or KOR soft key to select the language.

Selecting the Menu Language and Font Size

• Selecting the Menu Language

Press the Menu soft key to display the Menu menu.

Press the ENG, JPN, CHN, or KOR soft key to select the language.

• Selecting the Font Size

Press the Menu Font Size soft key to select Small or Large.

The font size of the alphanumeric characters on the menu changes.
