19-13
IM 701310-01E
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
App
Index
Item Specifications
Immunity Complying standards
EN61326-1 Table 2 (for use in industrial locations)
EN61326-2-1
(applies to 701307, 701308, 701310, 701311, 101312, 701313, 701912, 701913, 701914,
701923, 701924, 701943, and 701974 with 701975)
Influence in the immunity environment (performance criterion A)
Noise increase: within �200 mV (when using 701943)
within �200 mV (when using 701974 with 701975)
within �2 V (when using 701913)
Test conditions: When 5 GS/s, envelope mode, 20 MHz BWL (10:1 probe attenuation setting),
and50-Ωterminationattheprobetip.
Cable condition: Same as the cable condition for emission.
Test Item: 1. Electrostatic discharge: EN61000-4-2
Air discharge: �8 kV, contact discharge: �4 kV, criteria B
2. Radiated immunity: EN61000-4-3
80 M to 1 GHz, 10 V/m, 1.4 G to 2 GHz, 3 V/m, 2.0 G to 2.7 GHz, 3 V/m, Criteria A
3. Conducted immunity: EN61000-4-6
3 V, criteria A
4. Electrical fast transient/burst : EN61000-4-4
Power line: �2 kV, signal line: �1 kV, criteria B
5. Power frequency magnetic field: EN61000-4-8
30 A/m, 50 Hz, criteria A
6. Surge immunity: EN61000-4-5
Between lines: �1 kV, common: �2 kV criteria B
7. Voltage dip and interruption: EN61000-4-11
1 cycle, both polarities, 100%, criteria A
Other, criteria C
Definitions of criteria A, B, and C
Criteria A:
Aforementioned “Influence in the immunity environment” is metAforementioned “Influence in the immunity environment” is met
during the test.
Criteria B: This
apparatus continues to operate without hang-up or fallingThis apparatus continues to operate without hang-up or falling
into uncontrollable conditions during the test. No change of
actual operating state or stored data is allowed.
Criteria C:
Temporary degradation, or loss of function or performance
which requires operator intervention or system reset occurs
during the testing.
19.11 General Specifications
