Page #139 background imageLoading...
Page #139 background image
5-106
IM 710105-17E
:GONogo[:ZPARameter]:NUMBer<x>:PARam
eter:ITEM
Function Sets or queries the specified waveform
parameter’s item for parameter determination.
Syntax
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:ITEM {<Parameter>}
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:ITEM?
<x> = 1 to 4
<Parameter> = {AMPLitude
|AVERage|AVGFreq
|AVGPeriod|BWIDth|DELay|DT|DUTYcycle|
ENUMber|FALL|FREQuency|HIGH|LOW|MAXim
um|MINimum|NOVershoot|NWIDth|PERiod|P
NUMber|POVershoot|PTOPeak|PWIDth|RISE
|RMS|SDEViation|TY1Integ|TY2Integ|V1
|V2
}
Example
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
ITEM AVERAGE
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
ITEM?
-> :GONOGO:ZPARAMETER:NUMBER1:PARAMET
ER:ITEM AVERAGE
:GONogo[:ZPARameter]:NUMBer<x>:PARam
eter:LIMit
Function Sets or queries the specified waveform
parameter’s upper and lower limits for parameter
determination.
Syntax
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:LIMit {<NRf>}
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:LIMit?
<x> = 1 to 4
<NRf> = See the DLM2000 Features Guide for
this information.
Example
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
LIMIT 0,1
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
LIMIT?
-> :GONOGO:ZPARAMETER:NUMBER1:PARAMET
ER:LIMIT 1.000E+00,0.000E+00
:GONogo[:ZPARameter]:NUMBer<x>:PARam
eter:TRACe
Function Sets or queries the specified waveform
parameter’s source waveform for parameter
determination.
Syntax
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:TRACe {<NRf>|BIT<x>|FFT<x>|MATH<x
>|XY<x>}
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:TRACe?
<x> = 1 to 4
<NRf> = 1 to 4 (1 or 2 for 2-channel models)
<x> of BIT<x> = 1 to 8
<x> of FFT<x> = 1 or 2 (1 only for 2-channel
models)
<x> of MATH<x> = 1 or 2 (1 only for 2-channel
models)
<x> of XY<x> = 1 or 2 (1 only for 2-channel
models)
Example
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
TRACE 1
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
TRACE?
-> :GONOGO:ZPARAMETER:NUMBER1:PARAMET
ER:TRACE 1
:GONogo[:ZPARameter]:NUMBer<x>:PARam
eter:VALue?
Function Queries the specified waveform parameter’s
measured value for parameter determination.
Syntax
:GONogo[:ZPARameter]:NUMBer<x>:PARame
ter:VALue?
<x> = 1 to 4
Example
:GONOGO:ZPARAMETER:NUMBER1:PARAMETER:
VALUE?
-> :GONOGO:ZPARAMETER:NUMBER1:PARAMET
ER:VALUE1.98E−03
Description When the mode is set to OFF or when the value
is otherwise immeasurable, the DLM2000 returns
“NAN” (not a number).
:GONogo[:ZPARameter]:NUMBer<x>:POLYg
on?
Function Queries all polygonal zone determination settings.
Syntax
:GONogo[:ZPARameter]:NUMBer<x>:POLYg
on?
<x> = 1 to 4
5.13 GONogo Group
