5-56
IM 710105-17E
:ANALysis:AHIStogram<x>:MEASure:MODE
Function Sets or queries the measurement mode of a
waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEASure:MO
DE {OFF|PARameter}
:ANALysis:AHIStogram<x>:MEASure:MODE?
<x> = 1 or 2 (1 only for 2-channel models)
Example
:ANALYSIS:AHISTOGRAM1:MEASURE:MO
DE OFF
:ANALYSIS:AHISTOGRAM1:MEASURE:MODE?
-> :ANALYSIS:AHISTOGRAM1:MEASURE:MO
DE OFF
:ANALysis:AHIStogram<x>:MEASure:PARa
meter?
Function Queries all of the measurement settings for
a waveform histogram when the histogram
parameter measurement mode is set to Param.
Syntax
:ANALysis:AHIStogram<x>:MEASure:PARam
eter?
<x> = 1 or 2 (1 only for 2-channel models)
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:ALL
Function Collectively turns on or off all of the measurement
items of a waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEAS ure:PARa
meter:ALL {<Boolean>}
<x> = 1 or 2 (1 only for 2-channel models)
Example
:ANALYSIS:AHISTOGRAM1:MEASURE:PARAMET
ER:ALL ON
:ANALysis:AHIStogram<x>:MEASure:PARa
meter:<Parameter>?
Function Queries all of the settings for the specified
measurement item of a waveform histogram.
Syntax
:ANALysis:AHIStogram<x>:MEASure:PARam
eter:<Parameter>?
<x> = 1 or 2 (1 only for 2-channel models)
<Parameter > = {
C1|C2|DC|MAXimum|MEAN|
MEDian|MINimum|PEAK|SD2integ|
SD3integ|SDEViation|SDINteg
}
5.3 ANALysis Group
The power supply analysis feature (
:ANALysis:PANalyze
and
:ANALysis:PMEAsure
commands)
is an
option available only for 4-channel models. Power supply analysis commands cannot be used on 2-channel models
or 4-channel models without the power supply analysis option.
:ANALysis?
Function Queries all of the settings for the analysis feature.
Syntax
:ANALysis?
:ANALysis:AHIStogram<x>?
Function Queries all of the settings for the waveform
histogram feature.
Syntax
:ANALysis:AHIStogram<x>?
<x> = 1 or 2 (1 only for 2-channel models)
:ANALysis:AHIStogram<x>:DISPlay
Function Sets or queries the on/off status of a waveform
histogram display.
Syntax
:ANALysis:AHIStogram<x>:DISPlay {<Boo
lean>}
:ANALysis:AHIStogram<x>:DISPlay?
<x> = 1 or 2 (1 only for 2-channel models)
Example
:ANALYSIS:AHISTOGRAM1:DISPLAY ON
:ANALYSIS:AHISTOGRAM1:DISPLAY?
-> :ANALYSIS:AHISTOGRAM1:DISPLAY 1
:ANALysis:AHIStogram<x>:HORizontal
Function Sets or queries the horizontal range of a waveform
histogram.
Syntax
:ANALysis:AHIStogram<x>:HORizont
al {<NRf>,<NRf>}
:ANALysis:AHIStogram<x>:HORizontal?
<x> = 1 or 2 (1 only for 2-channel models)
<NRf>=−4to4(divisions)
Example
:ANALYSIS:AHISTOGRAM1:HORIZONTAL 0,1
:ANALYSIS:AHISTOGRAM1:HORIZONTAL?
-> :ANALYSIS:AHISTOGRAM1:HORIZONT
AL 1.000E+00,0.000E+00
:ANALysis:AHIStogram<x>:MEASure?
Function Queries all of the settings for waveform histogram
measurement (including the mode on/off status).
Syntax
:ANALysis:AHIStogram<x>:MEASure?
<x> = 1 or 2 (1 only for 2-channel models)
To Next Page
