Page #161 background image
5-128
IM 710105-17E
:MEASure:BIT<x>:AREA2:<Parameter>:CO
UNt?
Function Queries the statistical processing count of a logic
waveform parameter in Area2.
Syntax
:MEASure:BIT<x>:AREA2:<Parameter>:COU
Nt?
<x> = 1 to 8
<Parameter> = {
AVGFreq|DELay|DUTYcycle|
FREQuency|PERiod|PNUMber
}
Example (Below is an example for the average frequency of
bit 1.)
:MEASURE:BIT1:AREA2:AVGFREQ:COUNT?
-> :MEASURE:BIT1:AREA2:AVGFREQ:
COUNT 100
:MEASure:BIT<x>:AREA2:<Parameter>:{M
AXimum|MEAN|MINimum|SDEViation}?
Function Queries a statistical value of a logic waveform
parameter in Area2.
Syntax
:MEASure:BIT<x>:AREA2:<Parameter>:{MA
Ximum|MEAN|MINimum|SDEViation}?
<x> = 1 to 8
<Parameter> = {
AVGFreq|DELay|DUTYcycle|
FREQuency|PERiod|PNUMber
}
Example (Below is an example for the average frequency of
bit 1.)
:MEASURE:BIT1:AREA2:AVGFREQ:MAXIMUM?
-> :MEASURE:BIT1:AREA2:AVGFREQ:MAXIM
UM 10.0000E+03
Description If the statistical value is immeasurable, the
DLM2000 returns “NAN” (not a number).
:MEASure:BIT<x>:AREA2:<Parameter>:ST
ATe
Function Sets or queries the on/off status of a logic
waveform parameter in Area2.
Syntax
:MEASure:BIT<x>:AREA2:<Parameter>:STA
Te {<Boolean>}
:MEASure:BIT<x>:AREA2:<Parameter>:STA
Te?
<x> = 1 to 8
<Parameter> = {
AVGFreq|DUTYcycle|FREQuen
cy|PERiod|PNUMber
}
Example (Below is an example for the average frequency of
bit 1.)
:MEASURE:BIT1:AREA2:AVGFREQ:STATE ON
:MEASURE:BIT1:AREA2:AVGFREQ:STATE?
-> :MEASURE:BIT1:AREA2:AVGFREQ:
STATE 1
5.20 MEASure Group
You cannot use commands that relate to logic waveforms on models that are not equipped with logic inputs.
:MEASure?
Function Queries all of the settings for automated
measurement of waveform parameters.
Syntax
:MEASure?
:MEASure:BIT<x>?
Function Queries the on/off status of all parameters of a
logic waveform.
Syntax
:MEASure:BIT<x>?
<x> = 1 to 8
:MEASure:BIT<x>:ALL
Function Collectively turns on or off all measurement items
of a logic waveform.
Syntax
:MEASure:BIT<x>:ALL {<Boolean>}
<x> = 1 to 8
Example
:MEASURE:BIT1:ALL ON
:MEASure:BIT<x>:AREA2?
Function Queries all of the on/off status of a parameter of a
logic waveform in Area2.
Syntax
:MEASure:BIT<x>:AREA2?
<x> = 1 to 8
:MEASure:BIT<x>:AREA2:ALL
Function Collectively turns on or off all measurement items
of a logic waveform in Area2.
Syntax
:MEASure:BIT<x>:AREA2:ALL {<Boolean>}
<x> = 1 to 8
Example
:MEASURE:BIT1:AREA2:ALL ON
:MEASure:BIT<x>:AREA2:<Parameter>?
Function Queries the setting of a waveform parameter of a
logic waveform in Area2.
Syntax
:MEASure:BIT<x>:AREA2:<Parameter>?
<x> = 1 to 8
<Parameter> = {
AVGFreq|DELay|DUTYcycle|
FREQuency|PERiod|PNUMber
}
