2-2
IM 710105-17E
2.2 Ethernet Interface Features and Specifications
Ethernet Interface Features
Reception Features
Allow you to specify the same settings that you can using the front panel keys.
Receive output requests for measured and computed data, panel setting data, and error codes.
Transmission Features
The DLM2000 can transmit measured and computed data.
The DLM2000 can transmit panel setting data and the status byte.
The DLM2000 can transmit error codes when errors occur.
Ethernet Interface Specifications
Electrical and mechanical specifications: IEEE802.3
Simultaneous connections: 1
Protocol: VXI-11
Connectable PCs: A PC running Windows 7 (32 bit), Windows Vista (32 bit), or Windows XP.
Data Transfer Rate
The following table contains approximations of how much time it takes for the DLM2000 to transmit
waveform data.
Model: 710130
Controller: PC (Intel (R) Core (TM) i5 CPU 650 @ 3.2 GHz 3.33 GHz), Ether (Intel (R)
82578DM Gigabit Network Connection), OS (Windows 7 Enterprise 32 bit)
Programming language: Visual C++
Number of Data Points Byte Data Word Data ASCII Data
1250 Approx. 14 ms Approx. 13 ms Approx. 0.80 s
12500 Approx. 23 ms Approx. 16 ms Approx. 0.68 s
125000 Approx. 115 ms Approx. 43 ms Approx. 6.68 s
1250000 Approx. 1017 ms Approx. 288 ms Approx. 64.34 s
12500000 Approx. 10063 ms Approx. 2760 ms Approx. 659.26 s
125000000 Approx. 100055 ms Approx. 27141 ms Approx. 6676.55 s
